TV Tuner
Integrated Tuners*	PAL-I, DVB-T, DVB-T/T2 (MPEG4-AVC [H.264]), DVB-C (MPEG4-AVC [H.264])
Teletext Reception	500P Level 2.5, FASTEXT/LIST/TOP

Display
Contrast	Superb Contrast (2,000,000:1 Dynamic)
Motion Technology	600 Hz Sub Field Drive
Screen Size	42" (106 cm) diagonal
Panel	Progressive HD Plasma Display Panel with Tough Panel
Viewing Angle	Viewing Angle Free
Response Speed	0.001 msec. (Time of discharge after the drive pulse signal of the panel is sent.)
Resolution	1,024 x 768 (16:9)
Applicable Scanning Format
FULL-HD	1080p (HDMI only), 1080i
HD	720p
SD	576i/p, 480i/p
Moving Picture Resolution	720 lines
24p Smooth Film/Playback	24p Playback
Shades of Gradation	4,096 equivalent steps of gradation
Deep Colour (10/12-bit)	yes
x.v. Colour	yes
Picture Mode	Dynamic/Normal/Cinema/True Cinema/Game
Vreal	Vreal Plus

Sound
Speakers	2 x 10 watt 2 Speakers
Sound Mode	Music/Speech/User
Virtual Surround	V-Audio
Dolby Digital/dts/CoNEQ	Dolby Digital Plus//dts Digital Out

Input/Output
CI (Common Interface)	yes
VIERA Image Viewer	yes (AVCHD/SD-VIDEO/JPEG/MP3/AAC playback)
HDMI Input/ Support Feature	2 (rear)/ Audio Return Channel (Input 2)
Composite Video Input	AV2: CVBS x 1 (rear)
Component Video Input	RCA phono type x 1 set (rear)
Audio Input (for HDMI, Composite, Component)	RCA phono type x 1 set (rear)
21-Pin Input/Output	AV1: AV In/Out, S-Video In, RGB In, Q-Link (rear)
LAN Port	yes
Digital Audio Output (Optical)	yes
Headphone Jack	1 (side)

Features
Eco Navigation	yes
EPG (Now and Next)	yes
EPG for DVB-T (7days)	Gemstar EPG: UK, Italy, Germany, Spain; 7-Days SI EPG: France, Sweden
VIERA Tools	yes
VIERA Link	yes (HDAVI Control 5)
Multi Window	PAT
Game Mode	yes
Q-Link	yes
Off Timer	yes
Child Lock	yes

General
On mode Average Power Consumption***	92 W
Power Save Mode	yes
Power Supply	AC 220 - 240 V, 50/60Hz
Rated Power Consumption	150 W
Standby Power Consumption	0.4 W
Dimensions (W x H x D) (w/o stand)	1,023 x 637 x 93 mm
Dimensions (W x H x D) (with stand)	1,023 x 671 x 288 mm
Weight (w/o stand)	23.5 kg
Weight (with stand)	26.5 kg
Wall Bracket	TY-WK4P1RW

Further Specifications

NOTE

* Contrast Automatic Tracking System / ** Based on IEC 62087 Ed.2 measurement method. / ***Notice for DVB functions: / This TV is designed to meet the standards (current as of August, 2009) of DVB-T/C/S/S2 (MPEG2 and MPEG4-AVC [H.264]) services. / The compatibility with future DVB services is not guaranteed. / DVB-T MPEG4-AVC broadcast is available in selected countries: Denmark, Spain, Estonia, France, Lithuania, Norway, Slovenia, Sweden, Poland, Hungary, Portugal. / DVB-C feature is available only in following countries: / Sweden (ComHem, Canal Digital), Demark (YouSee), Norway (Canal Digital), Finland (Cable Ready HD), Germany, Switzerland, Netherlands / The country list above is as of January 1st, 2010. / Check the latest information on the available services at the following website (English only): / http://panasonic.jp/support/global/cs/tv/ / ****Depending on the area, this accessory may not be included.
